Cast Mini input output module
Cast Mini input output module
The CAST CA734 Mini IO Module is loop powered and compatible with C-TEC?s CAST ZFP/XFP panels and other ?CAST? compatible fire panels. The module incorporates a monitored switch input and a changeover relay output.
Features
- LPCB certified to EN54-17 & 18 and Kiwa Telefication & DBI certified to EN54-13.
- Also certified to the relevant parts of EN54 with Swedish certification body SBSC.
- Includes a switch monitor, signal relay and onboard loop isolator.
- 7mA typical alarm current (1mA typical quiescent current) @ 22-40V DC.
- Four plastic tabs for surface or panel mounting.
- Includes a 1A 30V DC volt-free changeover relay. Can also switch 0.3A @125V AC.
- Offers Switch +Ve, –Ve, LED +V, –Ve and changeover relay connections
- Future header pin offers expansion opportunities for peripheral I/O devices.
