Flair Detection Technology

Flair is the revolutionary detection chamber that forms the core of the VESDA-E VEP, providing higher stability and increased longevity. Direct imaging of the sampled particles using a CMOS imager combined with multiple photo-diodes allows better detection and fewer nuisance alarms.

Installation, Commissioning and Operation

VESDA-E VEP is equipped with a powerful aspirator that enables use of a total of 130m (427ft) of sampling pipe in the one pipe model and 560m (1,837ft) of pipe in the four pipe model. Out of box operation is made possible with AutoConfig which allows airflow normalisation and AutoLearn Smoke and Flow to be initiated from within the detector. VEP is fully supported by the ASPIRE and Xtralis VSC software applications which facilitate ease of pipe network design, system commissioning and maintenance.

VESDAnet™

VESDA devices communicate on VESDAnet which provides a robust bidirectional communication network allowing continued redundant operation even during single point wiring failures. VESDAnet enables primary reporting,centralized configuration, control, maintenance and monitoring.

Ethernet and WiFi connectivity

VESDA-E detectors offer Ethernet and WiFi connectivity as standard features. The detector can be added to a corporate network, allowing WiFi enabled tablet devices and PC’s installed with Xtralis monitoring and configuration software to connect wirelessly to the detector via the network.

Backward Compatibility

VESDA-E VEP is compatible with existing VESDA installations. The detector occupies the same mounting footprint, pipe, conduit and electrical connector positioning as VESDA VLP. VEP is also compatible with existing VESDAnet installations allowing monitoring of both VESDA-E and legacy detectors via the latest iVESDA application.

Features

• One and four pipe models for different applications
• Flair detection technology delivers reliable very early warning in a wide range of environments with minimal nuisance alarms
• Multi stage filtration and optical protection with clean air barriers ensures lifetime detection performance
• Four alarm levels and a wide sensitivity range deliver optimum protection for the widest range of applications
• Intuitive LCD icon display provides instant status information for immediate response
• Flow fault thresholds per port accommodate varying airflow conditions
• Smart on-board filter retains dust count and remaining filter life for predictable maintenance
• Extensive event log (20,000 events) for event analysis and system diagnostics
• AutoLearn™ smoke and flow for reliable and rapid commissioning
• Referencing to accommodate external environmental conditions to minimise nuisance alarms
• Backward compatible with VLP and VESDAnet
• Remote monitoring with iVESDA for system review and proactive maintenance
• Ethernet for connectivity with Xtralis software for configuration, secondary monitoring and maintenance
• Industry first. Aspirating detector secondary monitoring and maintenance via WiFi
• USB for PC configuration, and firmware upgrade using a memory stick
• Two programmable GPIs (1 monitored) for flexible remote control
• Field replaceable sub-assemblies enable faster service and maximum uptime
