Features

• Approved for use in Class A, B and C, according to EN54-20
• Provides Very Early Warning Fire Detection, as precise as 0.00095%/m obscuration
• Three alarm levels and three sensitivity modes provide application flexibility
• User configurable 3-speed fan, allowing for maximum coverage area or minimizing on current consumption
• Ultrasonic flow sensing and chamber airflow monitoring for precise system health information
• Dual source optical detection chamber with enhanced algorithms provide high sensitivity with greater immunity to nuisance conditions
• Patented particle separator removes large, non-fire particulate, ensuring chamber health and extending the life of the field-replaceable filter
• TCP and Serial Modbus for easy integration with building management systems
• Easy configuration via USB interface, no external power needed
• Onboard Ethernet interface enables remote monitoring, configuration, web server and e-mail notifications
• Multilingual LCD user interface allows for detailed device information and interaction such as: Active faults, precise airflow monitoring, reset of airflow baseline, test/reset/isolate and more
• Configurable air flow fault thresholds and verification period
• Convenient wiring compartment
• Status-at-a-glance provides immediate alarm, fault and airflow status
