Single Zone AOV Panel

Image 1

Single Zone AOV Panel

  • AOV-3016
  • Haes
  • SZAOV-1001

The SZAOV has been developed to provide a comprehensive and flexible solution to smoke vent control scenarios. Purpose designed single detection zone automatic opening vent control panel to use with vents, windows and roof lights.

EMAIL ENQUIRY 01706 658 880

Features

  • 3 amp integral PSU
  • Easy to program
  • Single detection zone,
  • Conventional or Twin-wire
  • Input from other detection systems, to activate
  • Monitored Actuator output for controlling smoke vents
  • Fireman switch input to override all other inputs
  • All inputs and actuator outputs monitored for Short and Open Circuit
  • Thermostat input - Ventilation mode. Vents openable in 10% steps
