Features

• 3 amp integral PSU
• Large graphical display
• Easy to program
• Up to 4 detection zones, Conventional and Twin-wire
• Up to 4 external inputs from other detection systems, to activate
• Up to 4 monitored Actuator outputs for controlling smoke vents
• Switch inputs to control wide combination of vents
• Fireman switch input to override all other inputs
• All inputs and actuator outputs monitored for Short and Open Circuit
• User switch inputs configurable as local fireman switches
• Thermostat input - Ventilation mode. Vents openable in 10% steps
• Actuators configurable for independent operation or linked together as per required by 12101-9
• Optional support for Rain sensor, PIR and BMS control
• Staggered start of actuators to avoid the combined start-up currents from simultaneous actuator activations
• Monitoring of unused inputs and outputs can be disabled

Downloads

• Technical Datasheet (PDF)
