3A - 1 Zone AOV Control Panel (non extendable)

Image 1

3A - 1 Zone AOV Control Panel (non extendable)

  • AOV-3011
  • Haes
  • MZAOV-1001A

AOV-3011 is a single detection zone, non extendable, smoke vent control panel with integral 3 amp power supply, designed to control 24vdc actuators or magnets.

EMAIL ENQUIRY 01706 658 880

Features

  • 3 amp integral PSU
  • Large graphical display
  • Easy to program
  • Single detection zone, Conventional or Twin-wire
  • Input from other detection systems, to activate
  • Monitored Actuator output for controlling smoke vents
  • Switch input to control wide combination of vents
  • Fireman switch input to override all other inputs
  • All inputs and actuator outputs monitored for Short and Open Circuit
  • User switch inputs configurable as local fireman switches
  • Thermostat input – Ventilation mode. Vents openable in 10% steps
  • Optional support for Rain sensor, PIR and BMS control
  • Monitoring of unused inputs and outputs can be disabled
