Quantec PIR Power Interface

Image 1

Quantec PIR Power Interface

  • NC-2116
  • C-Tec
  • QT645

Allows up to two QT638 PIR movement sensors to be connected to a Quantec addressable call system.

EMAIL ENQUIRY 01706 658 880

Features

  • Connects to the slave input on a QT602 or QT609 Range Call Point.
  • Typically located outside a bedroom where, for example, two PIRs are being used to monitor a patient getting out of bed.
  • Includes an isolation keyswitch so staff entering the room can temporarily disable the PIRs from triggering a call.
  • Derives its power from the Quantec network (no need for a separate power supply unit)
  • A maximum of 16 QT645s can be connected to a Quantec system.
  • Mounts on a standard UK 25mm single gang flush or surface back box.
