Quantec Interface Unit c/w remote socket

Image 1

Quantec Interface Unit c/w remote socket

  • NC-2114
  • C-Tec
  • QT636

Allows any device with a normally open or normally closed 6.35mm (1/4 inch) jack plug to be connected to Quantec.

EMAIL ENQUIRY 01706 658 880

Features

  • Particularly suited for use with our NC805MD Portable Movement Detector (n/o operation), QT644 Floor Pressure mat (n/o operation), QT633 Bed Exit mat (n/c operation) or QT634 Chair Exit Mat (n/c operation).
  • Must be wired as a slave to a QT602 or QT609 range addressable call point or QT630 dementia care controller.
  • When the device connected to the QT636 is operated a call will be generated on the Quantec call system as programmed.
  • Mounts on a standard UK 25mm single gang back box.
