Hush Button - Hochiki

Image 1

Hush Button - Hochiki

  • AP-4022
  • C-Tec
  • XFP508H

The XFP508H Hush Button has been specifically designed to reduce the incidence of false alarms in houses of multiple occupation by providing reliable, fully monitored fire detection, alarm and silencing facilities INSIDE each individual flat or apartment.

EMAIL ENQUIRY 01706 658 880

Features

  • Upgrades the level of protection offered in a flat or apartment from the Grade D minimum (mains/battery smoke alarms) to Grade A or B
  • Provides each individual dwelling with a 2 minute silence facility and 15 minute isolate facility to BS 5839 pt 6 clause 12.2
  • Can be operated by building occupants whilst standing at floor level
  • Includes a built-in loop isolator, conventional sounder circuit, conventional detector circuit and three status LEDs
  • Fully monitored for open and short circuit faults (logging facilities at the host panel give full traceability of any problems)
  • Failsafe operation - a general fire condition at the host panel will override any silenced/isolated state at the hush button and immediately turn on its local sounders
  • Operation of a manual call point fitted with a resistor of less than 400 ohm will immediately trigger the host panel (a 330 Ohm resistor is supplied - see inside for wiring details)
  • Common OV line allows sounders and detectors to be wired in three core cable
