CO Fire + Smoke + Heat Multisensor c/w Tone Sounder & C-3-9.4 White VAD

Image 1

CO Fire + Smoke + Heat Multisensor c/w Tone Sounder & C-3-9.4 White VAD

  • CP411TV
  • C-Tec
  • CP411TV

Proven false alarm reduction and protection from fire like never before – introducing CAST-PRO, C-TEC’s new range of integrated fire detection & alarm devices.

EMAIL ENQUIRY 01706 658 880

Features

  • Multiple functionality in a single device – CO fire, heat & smoke multisensor fire detection plus a 92db(A) tone Alarm sounder and a C-3-9.4 VAD – detects real fires quickly, reduces false alarms effectively and indicates true alarm conditions decisively.
  • Certified to EN54-3, 5, 7, 17, 23, 29 & 31.
  • Compatible with C-TEC’s ZFP and XFP CAST protocol addressable fire panels.
  • MASC™ (Miniature Advanced Smoke Detection Chamber) and AFFIRM™ algorithms provide incredible tolerance to false alarms whilst enhancing the detection of real fire conditions.
  • Drift compensation functionality.
  • Onboard short circuit loop isolator.
  • Includes two 8mm x 2mm ultra-bright red LED indicating strips.
  • Multiple detection modes and different sensitivities for different times of the day.
  • 13.2mA max. alarm current (max vol, VAD on).
  • 630uA typical quiescent current @ 22-40V DC.
  • Compatible with C-TEC’s CA408 CAST base c/w integrated locking mechanism & ID tag.
